UNS N04400 AMS 4544 Annealed Cold Rolled Steel Plate / Sheet 2mm Thk

UNS N04400 AMS 4544 Annealed Cold Rolled Steel Plate / Sheet 2mm Thk
UNS N04400 AMS 4544 Annealed Cold Rolled Steel Plate / Sheet 2mm Thk UNS N04400 AMS 4544 Annealed Cold Rolled Steel Plate / Sheet 2mm Thk

Large Image :  UNS N04400 AMS 4544 Annealed Cold Rolled Steel Plate / Sheet 2mm Thk

Product Details:
Place of Origin: China/Japan/Germany
Brand Name: METAL
Certification: ISO/PED/TUV/SGS/LR/BV
Model Number: Alloy 400
Payment & Shipping Terms:
Minimum Order Quantity: 300 Kilogram/Kilograms
Price: Negotiation
Packaging Details: In bulk in bundles plastic outside in bundles as customer's request.
Delivery Time: 10 working days
Payment Terms: L/C, T/T
Supply Ability: 50 Metric Ton/Metric Tons per Month

UNS N04400 AMS 4544 Annealed Cold Rolled Steel Plate / Sheet 2mm Thk

Description
Surface Treament: Coated,Galvanized,Black Product Name: Steel Coil, Sheet, Plate
Standard: ASTM, AISI, DIN, EN, GB Type: Coil, Plate, Sheet
Application: Widely Usage Technology: Hot Rolled / Cold Rolled
Length: Customers' Requirement Material: Alloy 400
High Light:

AISI Cold Rolled Steel Plate

,

UNS N04400 Annealed Steel Plate

,

AMS 4544 Cold Rolled Plate

Nickel Alloy 400 Sheets / Plates





Stockiest and Supplier of Alloy 400 plates or Alloy 400 in the annealed condition in thicknesses from 3/16" (4.8mm) through 3" (76.2mm). Alloy 400, in the annealed condition, shown moderate strength. The alloy is also available in the as-rolled condition (Alloy 400AR) which imparts higher strength to the alloy. Alloy 400AR is stocked in thicknesses from .1875" through 3.00".


Available thicknesses for Alloy 400

3/16"

1/4"

3/8"

1/2"

5/8"

3/4"

1"

4.8mm

6.3mm

9.5mm

12.7mm

15.9mm

19mm

25.4mm

1 1/4"

1 1/2"

1 3/4"

2"

2 1/2"

3"



31.8mm

38.1mm

44.5mm

50.8mm

63.5mm

76.2mm





Alloy 400 (UNS N04400) is a ductile nickel-copper alloy with resistance to a spread of corrosive conditions. The alloy is most frequently laid out in environments starting from mildly oxidizing through impartial and in moderately reducing conditions. An additional application place of the material is in marine environments and different non-oxidizing chloride answers.


Applications

• Chemical Processing Equipment – in fluorine, hydrofluoric acid, hydrogen fluoride, hydrochloric acid, sulfuric acid, neutral and alkaline salt solutions, caustic alkalies, non-oxidizing halides and dry chlorine service.

• Marine Components – shipbuilding, valves, pumps, shafts and in sea and brackish water

• Oil and Gas Production – splash-zones for offshore structures and sour gas applications

• Ore Processing – uranium refining and separation in the production of nuclear fuels

• Petroleum Refining – alkylation units, crude petroleum stills, piping and storage tanks

• Power Generation – feed-water heaters and steam generators

• Water Treatment – brine heaters and evaporators in seawater desalination plants


Standards

ASTM..................B 127
ASME..................SB 127
AMS ...................4544
Federal............... QQ-N-281


Chemical Analysis

Weight % (all values are maximum unless a range is otherwise indicated)


Nickel (plus Cobalt)

63.0 min.-70.0 max.

Iron

2.50

Copper

28.0 min.-34.0 max.

Sulfur

0.024

Carbon

0.3

Silicon

0.5

Manganese

2.0





Mechanical Properties

Nominal Room-Temperature Mechanical Properties of Alloy 400 and 400AR


FORM AND CONDITION

Yield Strength
0.2% Offset

Tensile Strength

Elongation, %

Hardness

ksi

MPa

ksi

MPa

Brinell (3000-kg)

Rockwell B

Plate















Hot-Rolled, As-Rolled

40-75

276-517

75-95

517-655

45-30

125-215

70-96

Hot-Rolled, Annealed

28-50

193-345

70-85

482-586

50-35

110-140

60-76
