Product Details:
|
| Product Name: | Alloy 825 Steel Plate | Surface: | 2B , BA , 8K Mirror |
|---|---|---|---|
| Thickness: | 5MM | Standard: | ASTM, AISI, DIN, EN, GB |
| Width:: | 1500MM | Application: | Various Applications |
| Technology: | Coil, Plate, Hot Rolled / Cold Rolled | Length: | 6000MM |
| High Light: | Nickel Alloy 825 Steel Plate,SGS Cold Rolled Plate,6000MM Length Cold Rolled Plate |
||
| 3/16" | 1/4" | 3/8" | 1/2" | 5/8" | 3/4" |
| 4.8mm | 6.3mm | 9.5mm | 12.7mm | 15.9mm | 19mm |
| 1" | 1 1/4" | 1 1/2" | 1 3/4" | 2" | |
| 25.4mm | 31.8mm | 38.1mm | 44.5mm | 50.8mm |
o Fuel Reprocessing
o Fuel Element Dissolvers
o Waste Handling
| Nickel | 38.0 min.–46.0 max. | Iron | 22.0 min. |
| Chromium | 19.5 min.–23.5 max. | Molybdenum | 2.5 min.–3.5 max. |
| Molybdenum | 8.0 min.-10.0 max. | Copper | 1.5 min.–3.0 max. |
| Titanium | 0.6 min.–1.2 max. | Carbon | 0.05 max. |
| Niobium (plus Tantalum) | 3.15 min.-4.15 max. | Titanium | 0.40 |
| Carbon | 0.10 | Manganese | 1.00 max. |
| Sulfur | 0.03 max. | Silicon | 0.5 max. |
| Aluminium | 0.2 max. |
| Yield Strength 0.2% Offset |
Ultimate Tensile Strength |
Elongation in 2 in. |
Hardness | ||
| psi (min.) | (MPa) | psi (min.) | (MPa) | % (min.) | Rockwell B |
| 49,000 | 338 | 96,000 | 662 | 45 | 135-165 |
| Temperature,°F | 70 | 400 | 600 | 800 | 1000 | 1200 | 1400 | 1600 |
| Ultimate Tensile Strength, ksi | 144 | 134 | 132 | 132 | 130 | 119 | 78 | 40 |
| 0.2% Yield Strength, ksi | 84 | 66 | 63 | 61 | 61 | 60 | 59 | 39 |
| Elongation, % | 44 | 45 | 42.5 | 45 | 48 | 34 | 59 | 117 |
| Temperature, °F | 1200 | 1300 | 1400 |
| 100 Hours, ksi | 59 | 34 | 18 |
| 1,000 Hours, ksi | 43 | 23 | 12 |
