5000 Series Aluminium Alloy Plate 0.3 - 350MM Thickness For Marine / Boat

Certification
Good quality Super Duplex Stainless Steel Pipe for sales
Good quality Super Duplex Stainless Steel Pipe for sales
In the latest vendor rating, TOBO won the excellent rating, it is good, will continue to cooperate.

—— Brazil---Aimee

ASTM A213 T9 Alloy steel pipe ,Stable quality , good price, excellent serive, TOBO GROUP is our trustworthy partner

—— Thailand ---Dave Mulroy

I'm Online Chat Now

5000 Series Aluminium Alloy Plate 0.3 - 350MM Thickness For Marine / Boat

China 5000 Series Aluminium Alloy Plate 0.3 - 350MM Thickness For Marine / Boat supplier
5000 Series Aluminium Alloy Plate 0.3 - 350MM Thickness For Marine / Boat supplier 5000 Series Aluminium Alloy Plate 0.3 - 350MM Thickness For Marine / Boat supplier 5000 Series Aluminium Alloy Plate 0.3 - 350MM Thickness For Marine / Boat supplier

Large Image :  5000 Series Aluminium Alloy Plate 0.3 - 350MM Thickness For Marine / Boat

Product Details:

Place of Origin: China
Brand Name: TOBO
Certification: ISO/PED/TUV/SGS/LR/BV
Model Number: 5000

Payment & Shipping Terms:

Minimum Order Quantity: 1 Ton/Tons neogotiationTrial Order
Packaging Details: PLY-WOODEN CASE OR PALLET
Delivery Time: 10-100 days depending on quantity
Payment Terms: D/P, T/T, Western Union
Supply Ability: 3000 Ton/Tons per Week neogotiation
Contact Now
Detailed Product Description
Product Name: Aluminum Plate Product Type: Aluminum Coil
Grade: 5000 Series Thickness: 0.3-350MM
Width: 1000mm-3000mm Surface: 2B,BA,No1,No4
Quality Assurance: Mill Test Certificate Is Supplied With Shipment Application: Marine, Boat Application

5000 Series Aluminium Alloy Plate For Marine Aluminum Plate / Coil 0.3 - 350 MM Thick



Grade: 5000 Series Temper: T3-T8, O,T3,T4,T351,T361,etc Type: Plate
Application: Aerospace industry,Auto industry,Oil and Gas industry Thickness: 0.3-350mm Width: 1000-3000mm
Surface Treatment: Coated, brushed,polished,mill finished,power coated,sand blast. Alloy Or Not: Is Alloy Place of Origin: Shanghai, China (Mainland)
Brand Name: TOBO Model Number: 5005 Materia: 5005 aluminium alloy plate for marine
Packing: LCL,FCL,nude cargo,etc. Productive Technology: cold-drawing,hot rolling,cold rolling,forging,casting Surface Protection: oleophobic coating,protective film,paint coating
Certificate: SGS,CE,BV,UT,etc. Original: the People's Republic of China Payment Term: T/T,L/C,Western Union,etc.
Shape: Circle,Square,etc.

Product Description
Material aluminum alloy plate/sheet
Grade 2024,2014,3003,5052,6063,7075,etc.
Standard GB/T 6893-2000,GB/T6519-2000,GB/T 3190-2008,etc.
Shape round,square,rectangular,etc.
Thickness(mm)

2,3,6,8,10,12,14,16,18,20,22,25,28,30,32,35,38,40,42,45,48,50,

52,55,58,6065,70,75,80,85,90,95,100,105,110,115,120,125,130,

140,150,... ...,190,200.

Width(mm) 1000,1220,1250,1500,1620,1800,2000,2500,3000.
Length(mm) 2000,2440,2500,3000,3240,3600,4000,5000,6000.
Temper 0,F,T3,T5,T6,T651,T6510,etc.
Surface Treatment brushed,polished,mill finished,power coated,sand blast.
ProductiveTechnology hot rolling,cold rolling,forging,casting,etc.
Surface Protection oleophobic coating,protective film,paint coating
Packing LCL,FCL,nude cargo,etc.



Packaging & Delivery

Packaging Details: 5005 aluminium alloy plate for marine
Standard Seaworthy Packing
20ftGP:5898mm(Length)x2352mm(Width)x2393mm(High)
40ftGP:12032mm(Length)x2352mm(Width)x2393mm(High)
40ftHC:12032mm(Length)x2352mm(Width)x2698mm(High)
Delivery Detail: 3-7 days for stock size,20-35 days for custom size



Temper Description

F As fabricated (no mechanical property limits specified).
O

Annealed - products achieving the required annealed properties after hot forming

processes may be designated as O temper.

H112

Slightly strain-hardened from working at an elevated temperature from a limited

amount of cold work (mechanical property limits specified).

T3 Solution heat-treated, cold worked and naturally aged.
T351

Solution heat-treated, stress-relieved by controlled stretching (permanent set 0.5%

to 3% for sheet, 1.5% to 3% for plate, 1% to 3% for rolled or cold-finished rod and

bar, 1% to 5% for hand or ring forging and rolled ring)and naturally aged. The products

receive no further straightening after stretching.

T4 Solution heat-treated and naturally aged.
T5 Cooled from an elavated temperature shaping process and then artificially aged.
T6 Solution heat-treated and then artificially aged.
T651

Solution heat-treated, stress-relieved by controlled stretching (permanent set 0.5%

to 3% for sheet, 1.5% to 3% for plate, 1% to 3% for rolled or cold finished rod and

bar, 1% to 5% for hand or ring forging and rolled ring) and then artificially aged.

The products receive no further straightening after stretching.







.........................................
We create the best quality and service to meet customer requirement !
We look forward to having chance to star our long-term cooperation with friends from all of world !
You 100% satisfaction will always be our aim !
You will feel free to inquiry us please !
