Product Details:
|
| Place Of Origin:: | China | Brand Name:: | TOBO |
|---|---|---|---|
| Length:: | Customize | Outer Diameter:: | Customize |
| Standard:: | ASTM B337/338, AMSE SB337/338, ASTM F67, ASTM F136 | Technique:: | Seamless |
| Wall Thickness:: | Customize | Processing Service:: | Cutting |
| High Light: | Construction Nickel Alloy Tube,Customized Round Nickel Alloy Pipe,Nickel Alloy Pipe Inconel 600 |
||
| Product Name: | Nickel Alloy Pipe / Tube | Material: | Inconel 600 |
|---|---|---|---|
| Technique: | Seamless | Shape: | Pipe |
| Usage: | Construction Structure | Alloy Or Not: | Is Alloy |
| Color: | Silver | ||
| High Light: |
seamless alloy pipe,welded steel pipe |
||
Round Nickel Alloy Pipe Inconel 600 NO6600 For Construction Structure
Alloy 600/Inconel 600/NO6600/NS333/2.4816:
This alloy has the characteristics of corrosion resistance, heat resistance, oxidation resistance, easy machining and welding
Specification
Grades: Inconel 600 (UNS No. NO6600)
Standards: ASTM. ASME AND API
Specifications: ASTM B167.516.517 / ASME SB167.516.517
Size: 15'' NB TO 150'' NB IN
Length: Within 12000mm
Type: Seamless / ERW / Welded / Fabricated / LSAW Pipes
| Standard | Inconel600 |
| WERKSTOFF NR. | 2.4816 |
| UNS | NO6600 |
| AFNOR | NC15FE11M |
| GOST | MHXMu 28-2,5-1.5 |
| JIS | NCF 600 |
| BS | NA13 |
| Production Name | Nickel Alloy Steel Pipes |
| Standard | ASME/ANSI B16.9, ISO, JIS, DIN, BS,GB, SH, HG,QOST,ETC. |
| Size | 1/2’’~48’’(Seamless);16’’~72’’(Welded) |
| Wall thickness | Sch5~Sch160XXS |
| Manufacturing process | Push, Press, Forge, Cast, etc. |
| Nickel alloy steel | Alloy 400/Monel 400/NO4400/NS111/2.4360/ASTM B366 WPNC; Alloy K-500/Monel K-500/NO5500/2.475; Alloy 600/Inconel 600/NO6600/NS333/2.4816; Alloy 601/Inconel 601/NO6001/2.4851; Alloy 625/Inconel 625/NO6625/NS336/2.4856; Alloy 718/Inconel 718/NO7718/GH169/GH4169/2.4668; Alloy 800/Incoloy 800/NO8800/1.4876; Alloy 800H/Incoloy 800H/NO8810/1.4958; Alloy 800HT/Incoloy 800HT/NO8811/1.4959; Alloy 825/Incoloy 825/NO8825/2.4858/NS142; Alloy 925/Incoloy 925/NO9925; Hastelloy C/Alloy C/NO6003/2.4869/NS333; Alloy C-276/Hastelloy C-276/N10276/2.4819; Alloy C-4/Hastelloy C-4/NO6455/NS335/2.4610; Alloy C-22/Hastelloy C-22/NO6022/2.4602; Alloy C-2000/Hastelloy C-2000/NO6200/2.4675; Alloy B/Hastelloy B/NS321/N10001; Alloy B-2/Hastelloy B-2/N10665/NS322/2.4617; Alloy B-3/Hastelloy B-3/N10675/2.4600; Alloy X/Hastelloy X/NO6002/2.4665; Alloy G-30/Hastelloy G-30/NO6030/2.4603; Alloy X-750/Inconel X-750/NO7750/GH145/2.4669; Alloy 20/Carpenter 20Cb3/NO8020/NS312/2.4660; Alloy 31/NO8031/1.4562; Alloy 901/NO9901/1.4898; Incoloy 25-6Mo/NO8926/1.4529/Incoloy 926/Alloy 926; Inconel 783/UNS R30783; NAS 254NM/NO8367; Monel 30C Nimonic 80A/Nickel Alloy 80a/UNS N07080/NA20/2.4631/2.4952 Nimonic 263/NO7263 Nimonic 90/UNS NO7090; Incoloy 907/GH907; Nitronic 60/Alloy 218/UNS S21800 |
| Package | Wooden cases, pallets, nylon bags or according to the clients' requirements |
| Delivery time | 10-100 days depending on quantity |
| Payment terms | T/T or Western Union or LC |
| Shipment | FCA Tianjin/Shanghai, CFR, CIF, etc |
| Application | Petroleum/Power/Chemical/Construction/Gas/Metallurgy/Shipbuilding etc |
| Remarks | Other materials and drawings are available. |
| The third party inspection: | BV,SGS,LOIYD,TUV,and other party alloyed by clients. |
Corrosion resistance
UNS N06600 alloy has excellent corrosion resistance in atmospheric, water and steam media, and also in some weak acid,
dilute oxidizing and reducing acid. In all kinds of weak organic acids, the corrosion rate is also very low.
Product application
The comprehensive performance of the alloy has a strong corrosion resistance, widely used in chemical and other industries,
such as used in the manufacture of heater exchanger fatty acid treatment with condenser evaporator distillation kettle distillation
tower pavilion rosin acid with equipment because of the alloy at high temperature but also has high strength and good oxidation
resistance, and can also be used in heat treatment industry, manufacturing all kinds of parts in the nuclear power industry,
the alloy has good corrosion resistance to high temperature and high pressure water, so it is also an important structural material
for light water reactor nuclear power plant, the products are plate wire rods with pipes
Chemical Properties
| Grade | Ni | Fe | C | Mn | Si | Cu | Cr | S | Al |
| Inconel600 | 72.0 min | 6.0-10.0 | 0.15 max | 1.00 max | 0.50 max | 0.50 max | 14.0-17.0 | 0.015 max | - |
Mechanical Properties
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.4 g/cm3 | 1370-1425℃ | 550 min. | 240 min. | 30% |
