B16.9 WPHY42 WPHY52 WPHY65 DN4000 Schxxs Hot Forming Carbon Steel Butt Weld Pipe Fitting Barred Tee
Barred tee or pigged tee is a pipe fitting that is used in a pig launcher or receiver system in a piping system to ensure the pig could pass the branch safely.
The shape of a barred tee is like a butt welding pipe tee with some bars in the branch of the tee. The bars are used for preventing the pig from running out in the branch of the main pipe. It is commonly used in a pigged pipeline, so it is also called pigged tee. The bars in the branch should be installed flush with the inside diameter of main pipe. Commonly the bars are welded with the tees.
Dimensions : ANSI/ASME B16.9
Material: Tee body in A234 GR.WPB, guided bars in ASTM A36
Size : up to 100 inch or custom
Thickness : 1/2” to 7/8” depends on OD etc.
Test: UT, X-ray and mechanical properties etc.
Available materials in stainless Steel :
ASTM A403 WP 304/ 304L/ 304H/ 316/ 316L/ 317/ 317L/ 321/ 310/ 347/ 904L
Available materials in carbon steel
ASTM A234 WPB / A420 WPL3/ A420 WPL6/ MSS-SP-75 WPHY 42/46/52/56/60/65/70
Available materials in alloy steel
ASTM A234 WP1/ WP5/ WP9/ WP11/ WP22/ WP91
Available materials in duplex stainless steel
ASTM A815, ASME SA815 UNS NO S31803, S32205. Werkstoff No.1.4462
Packing&Delivery
1.Packing Details : Regular shipping packaging or depends on customer's requirement
2.Delivery Details : 7-15 days after the PO
Our Service
Why Choosing Metal Industrial:
-Sufficient Forging, Heating, Machining Equipment
-In-house Inspection Instruments for Quality Controlling
-Competitive Price & High Quality Assurance
-Fast, Effective and Efficient Services
-Directly supplier of Danieli Metallurgical Equipment
-Experienced Professinonals on Communication.
Our Company
1.We are one of the Professional manufacturers Exporter Pipeline products in China .Our company was established in 1998, the plant covers 550, 000 square meters and a construction area of 6,8,000square meters, existing 260 workers and 45 technicians.
2.We have five branch factories which can supply the best quality pipes, tubes, fittings flanges and related accessories. Now, it owns a number of advanced pipe production equipments, metal, forging, machining, cold forming, hot extrusion, such as heat treatment process, producing 60, 000 tons of pipe fittings. Company with a variety of detection devices, such as nondestructive testing, chemical analysis, metallographic examination, physical experiments. The technical is very strength, our main products contain fittingsforged socket welding fittings and threaded fittings, pipe weld and the materials of the products contain stainless steel ,duplex-stainless steel alloy steel.
3.In addition, we are authorized by more than 120 top-class mills from South Korea,Japan and China like JFE,SUMITOMO,POSCO,BAOSTEEL, TISCO,LISCO,.TPCO,HENGYANG VALIN and so on.
FAQ
Q: Are you trading company or manufacturer ?
A: We are factory.
Q: How long is your delivery time?
A: Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.
Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 50% T/T in advance ,balance before shippment.
