Product Details:
|
| Size: | According To ASTM Standard | Material: | ASTM B444 N06625 Gr.1 |
|---|---|---|---|
| Surface Finish: | Pickled And Annealed, Bright Annealed, Polished | Thickness: | 1mm - 80mm |
| Ultimate Strength: | ≥ 730 MPa | Ni (Min):: | 72% |
| Certificate: | BV , SGS, TUV, ABS 3.1 Certificate | Shipping: | By Air Or By Sea |
| High Light: | C22 Nickel Alloy Pipe,Gr1 Seamless Nickel Alloy Pipe,Hastelloy Round Steel Pipe |
||
Features
|
Chemical Position(%)
|
|||||||
|
Model
|
Ni
|
Cr
|
AI
|
C
|
Mn
|
Si
|
Fe
|
|
inconel 600
|
≥72
|
14–17
|
|
≤0.15
|
≤1.0
|
≤0.50
|
6–10
|
|
inconel 617
|
44.2–61
|
20–24
|
0.8–1.5
|
0.05–0.15
|
≤0.50
|
≤0.50
|
≤3.0
|
|
inconel 625
|
≥58
|
20–23
|
≤0.4
|
≤0.1
|
≤0.50
|
≤0.50
|
≤5.0
|
|
inconel 690
|
≥58
|
27–31
|
|
≤0.05
|
≤0.50
|
≤0.50
|
7–11
|
|
Nuclear grade 690
|
≥58
|
28–31
|
|
≤0.04
|
≤0.50
|
≤0.35
|
7–11
|
|
inconel 718
|
50–55
|
17–21
|
0.2–0.8
|
≤0.08
|
≤0.35
|
≤0.35
|
–
|
|
inconel X-750
|
≥70
|
14–17
|
0.4–1.0
|
≤0.08
|
≤1.0
|
≤0.50
|
5.0–9.0
|
ASTM/ASME Standards
ASTM A 213/A 213M ASME SA213/SA213M Specification for Seamless Ferric and Austenitic Alloy-Steel Boiler, Su[perheater, and Heat-Exchanger Tubes
ASTM A 249/A 249M Specification for Welded Austenitic Steel Boiler, Superheater, Heat-Exchanger, and Condenser tubes
ASTM A268/A268M, ASME SA268/SA268M Specification Seamless and welded ferritic and martensitic stainless steel tubing for general service
ASTM A269/A269M, ASME SA269/SA269M Specification for Seamless and Welded Austenitic Stainless Steel Tubing for General Service
ASTM A 270 Specification for Seamless and Welded Austenitic and Ferritic/Austenitic Stainless Steel Sanitary Tubing
Application
Nickel alloy pipe/plate/bar is used in Chemical processing, Liquid fuel rocket motor components, Pollution-control equipment , Cryogenic storage tanks, Valves, fasteners, springs, mandrels, tubing hangers,Well head completion equipment and blow out preventers (BOP’s) and Gas turbine engine parts
The softened and annealed low-carbon alloy 625 is widely used in the chemical process industry. Its good corrosion resistance and high strength enable it to be used as a thinner structural part. Alloy 625 can be used in situations where it is exposed to seawater and subjected to high mechanical stress. Typical application areas:
* Components of organic chemical processes containing chlorides, especially where acid chloride catalysts are used
* Used in the manufacture of digesters and bleaching tanks in the pulp and paper industry
* Absorption tower, reheater, flue gas inlet baffle, fan (wet), stirrer, baffle and flue in the flue gas desulfurization system
* Used to manufacture equipment and components used in acid gas environments
* Acetic acid and acetic anhydride reaction generator
* Sulfuric acid condenser
