Powerful Alloy Threaded Flanges B564 8811 6"900#

High Quality Powerful Alloy Threaded Flanges, B564 8811 6"900#

Flange is also called Flange or Flange plate.A flange is a part that connects a pipe to a pipe and is attached to the end of the pipe.Flange connection or flange joint refers to the detachable connection which is connected by flange, gasket and bolt as a group of assembled sealing structure. Pipe flange refers to the flange with pipe in the pipeline device, and refers to the import and export flange of the equipment when used in the equipment.There are holes in the flange and bolts hold the two flanges together.Gasket seals between flanges.Flanges threaded connection (threaded connection) flanges and welded flanges and clip flanges.Flange material
According to the production of material can be divided into: WCB (carbon steel), LCB (low temperature carbon steel), LC3 (3.5% nickel steel), WC5 (1.25% 0.5% chrome molybdenum steel), WC9 chromium (2.25%), C5 (% 5% chromium molybdenum), C12 (9% 1% chromium molybdenum), CA6NM (4 (12% chromium steel), CA15 (4) (12% chromium), CF8M(316 stainless steel), CF8C(347 stainless steel), CF8(304 stainless steel), CF3(304L stainless steel), CF3M(316L stainless steel), CN7M(alloy steel), M35-1(Monel), N7M(Hastert nickel alloy B),

CW6M(Hastert nickel alloy C), CY40(because ofNickel alloy)

Flange type: Threaded, Class: 150, Material: Forged 304 Stainless Steel, Dimensions conform to ANSI B16.5, Material conforms to ASTMA A182/SA 182, Nominal Pipe Size: ½, Flange outside diameter: 3.5 inches, Flange thickness: 0.44 inches, Diameter of Raised Face: 1.38 inches, Diameter of Hub at Base: 1.19 inches, Length thru Hub: 0.62 inches, Minimum thread length: 0.62 inches, Number of Bolt Holes: 4, Diameter of Bolt Holes: 0.62 inches, Diameter of Bolts: 0.5 inches, Diameter of Bolt Circle: 2.38 inches, Approximate weight: 1 lbs
