SCH40 ASTM B729 UNS N08020 Duplex Stainless Steel Pipe S31803

SCH40 ASTM B729 UNS N08020 Duplex Stainless Steel Pipe S31803
SCH40 ASTM B729 UNS N08020 Duplex Stainless Steel Pipe S31803 SCH40 ASTM B729 UNS N08020 Duplex Stainless Steel Pipe S31803 SCH40 ASTM B729 UNS N08020 Duplex Stainless Steel Pipe S31803

Large Image :  SCH40 ASTM B729 UNS N08020 Duplex Stainless Steel Pipe S31803

Product Details:
Place of Origin: China
Brand Name: METAL
Certification: SGS/BV/ABS/LR/TUV/DNV/BIS/API/PED
Model Number: API 5L API 5CT Pipe
Payment & Shipping Terms:
Minimum Order Quantity: 1PC
Price: Negotiation
Packaging Details: PLY-WOODEN CASE OR PALLET
Delivery Time: 5-8 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 10000 pcs per Month

SCH40 ASTM B729 UNS N08020 Duplex Stainless Steel Pipe S31803

Description
Product Name: API 5L API 5CT Pipe Material Grade: API 5L API 5CT
Steel Grade: S2205 S31803 S32750 S32760 Type: Seamless
Grade:: TP304/TP316L//TP310MOLN/TP316LMOD/S32205/S32750 Welding Line Type: Seamless
Size: 1-96 Inch Standard: ASTM A312
High Light:

UNS N08020 Duplex Stainless Steel Pipe

,

ASTM B729 Seamless Steel Pipe

,

S31803 Duplex Stainless Steel Pipe

ASTM A312 UNS S31254 PIPEUNS N10276 B619 1" SCH40 ASTM B729 UNS N08020 1 4462 DUPLEX STAINLESS STEEL PIPE

Product Description

1.Specifications about stainless steel Pipe

Brand Name TOBO
Product Name Hastelloy Alloy Pipe
Certification 3.1, chanrged Third party is available
Place of Origin Shanghai China (Mainland)
Outer Diameter DN10-DN1200,3/8"-100",6-2500mm
Wall Thickness SCH5-SCH160,XS,STD,XXS,0.5-150mm
Length 5.8m,6m,11.8m,12m,or as required























Material

Duplex: 2205(UNS S31803/S32205),2507(UNS S32750),UNS S32760,2304,LDX2101,LDX2404,LDX4404,904L;

Alloy : Alloy 20,Alloy 28,Alloy 31;
Hastelloy: Hastelloy B / B-2,Hastelloy B-3,Hatelloy C22,Hastelloy C-4,Hastelloy S,
Hastelloy C276,Hastelloy C-2000,Hastelloy G-35,Hastelloy G-30,Hastelloy X, Hastelloy N;
Haynes: Haynes 230,Haynes 556,Haynes 188;
Inconel: Inconel 600,Inconel 601,Inconel 602CA,Inconel 617,Inconel 625,Inconel 718,Inconel X-750;Carpenter 20;
Incoloy: Incoloy 800 / 800H / 800HT,Incoloy 825,Incoloy 925,Incoloy 926
GH: GH2132,GH3030,GH3039,GH3128,GH4180,GH3044
Monel: Monel 400,Monel K500
Nitronic: Nitronic 40,Nitronic 50,Nitronic 60;
Nimonic: Nimonic 75,Nimonic 80A,Nimonic 90 ;

Others: 254SMo,253Ma,F15,Invar36,1J22,N4,N6 etc
1.4057,1.4313,1.4362,1.4372,1.4378,1.4418,1.4482,1.4597,1.4615,1.4662,1.4669,
1.4913,1.4923 etc
Standard ASTM B 366, ASTM B 446, NACE MR 0175, ISO 15156,ISO6207, API 6A
Process Cold drawn, Cold rolled, Precision Rolled for Seamless Pipe or Tube
Finish Annealed & pickled, bright annealing, polished
Ends Beveled or plain end, square cut, burr free ,Plastic Cap at Both end


Application Petroleum/Power/Chemical/Construction/GaS/Metallurgy/Shipbuilding etc
MinimumOrder Quantity 1kg
Price Depending on quantity
Payment Terms T/T or Western Union or LC
Supply Ability 3,0000pcs per month
Delivery Time 10-50 days depending on quantity



Packaging Details

Bare packing/bundle packing with woven bag/wooden or steel frame crate packing/plastic cap protection at the both sides of tubes and suitably protected for sea-worthly delivery or as requested.



Tolerance

a) Outer Diameter: +/- 0.2mm
b) Thickness: +/- 0.02mm
c) Length: +/- 5mm
Surface pickled surface ,polish
Special design available as the requirement of customer

材料牌号・标准
NAS规格 ASTM A240/B463 EN JIS
NAS 335X UNS N08020
化学成分

ASTM A240
[wt %]

  C Si Mn P S Ni Cr Mo Cu Nb
规格 ≦ 0.07 ≦ 1.00 ≦ 2.00 ≦ 0.045 ≦ 0.035 32.0-
38.0
19.0-
21.0
2.00-
3.00
3.0-
4.0
8×C-
1.00


ASTM B463
[wt %]

  C Si Mn P S Ni Cr Mo Cu Nb
规格 ≦ 0.07 ≦ 1.00 ≦ 2.00 ≦ 0.045 ≦ 0.035 32.00-
38.00
19.00-
21.00
2.00-
3.00
3.00-
4.00
8×C-
1.00



Company Information



We are one of the Professional manufacturers Exporter Pipeline products in China .Our company was established in 1998, the plant covers 550, 000 square meters and a construction area of 6,8,000square meters, existing 260 workers and 45 technicians.



SCH40 ASTM B729 UNS N08020 Duplex Stainless Steel Pipe S31803 0

Packing & Shipping

Packing Details : Regular shipping packaging or depends on customer's requirement

Delivery Details : 7-15 days after the Payment



SCH40 ASTM B729 UNS N08020 Duplex Stainless Steel Pipe S31803 1



FAQ



Q:Are you trading company or manufacturer ?

A: We are factory.



Q: How long is your delivery time?

A: Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.



Q: Do you provide samples ? is it free or extra ?

A: Yes, we could offer the sample for free charge but do not pay the cost of freight.



Q: What is your terms of payment ?

A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 50% T/T in advance ,balance before shippment.
