DN50 2" Sch160 Thread Female Tee SS304 Forged Pipe Fittings

DN50 2inch Sch160 Thread Female Tee SS Forged Pipe Fittings 304 ASME B16.9

standards

ASME B16.9-2007

ASME B16.25-2007

ASME B16.5-2007

EN10253-1-1999 EN10253-2-2007 EN10253-3-2008 EN10253-4-2008

DIN2605-1-1992 DIN2605-2-1995

JIS B2311-2009 JIS B2312-2009 JIS B2313-2009

GB/T12459-2005 GB/T13401-2005 GB/T10752-2005

SH/T3408-1996 SH/T3409-1996

SY/T0609-2006 SY/T0518-2002 SY/T0510-1998

DL/T695-1999 GD2000 GD87-1101

HG/T21635-1987 HG/T21631-1990

Dtailed Production Description

1)Size: Seamless: 1/2”-60" SCH10s-XXS

2)Standard: ANSI B16.9/B16.11/B16.28, DIN, JIS, ISO

3)Material:carbon steel:A234-WPB WPC,

alloy steel :A420-WPL6, A234-WP11, A234-WP12, A234-WP5,A234-WP9,A234-WP22,15Mo3,15CrMoV,35CrmoV

stainless steel:A403 WP 304-304L-304H-304LN-304N

A403 WP 316-316L-316H-316LN-316N-316Ti

A403 WP 321-321H

A403 WP 347-347H

low tempture steel: A402 WPL3-WPL6

high performance steel: A860 WPHY 42-46-52-60-55-70

4)Surface treatment: carbon steel: shot blasted, black painting, rust-proof oil,transparent oil, galvanizing,hot galvanizing

alloy steel: Shot blasted, black painting, rust-proof oil,transparent oil, galvanizing,hot galvanizing

stainless steel: pickled ,Polish

5)Nominal wall thickness:SCH5-SCH160, STD, XS, XXS

6)Packing: Wooden case or wooden pallet according to the size of fittings

7)Delivery time:7-10 days for a 20 ft container

8)Others:1) Special design available 2)All the production process are made under the ISO 9001:2000 strictly.

Alloy 400

* Alloy 400 is slightly magnetic at room temperature.

* This alloy has a long history of use as a corrosion resistant material, dating back to the early 20th century when it was developed as an attempt to use a high copper content nickel ore. The nickel and copper contents of the ore were in the approximate ratio which is now formally specified for the alloy.

Chemical Composition, %

• UNS N04400
• Other common names: Alloy 40

Monel 400 is a nickel-copper alloy (about 67% Ni – 23% Cu) that is resistant to sea water and steam at high temperatures as well as to salt and caustic solutions. Alloy 400 is a solid solution alloy that can only be hardened by cold working. This nickel alloy exhibits characteristics like good corrosion resistance, good weldability and high strength. A low corrosion rate in rapidly flowing brackish or seawater combined with excellent resistance to stress-corrosion cracking in most freshwaters, and its resistance to a variety of corrosive conditions led to its wide use in marine applications and other non-oxidizing chloride solutions. This nickel alloy is particularly resistant to hydrochloric and hydrofluoric acids when they are de-aerated. As would be expected from its high copper content, alloy 400 is rapidly attacked by nitric acid and ammonia systems.

Monel 400 has great mechanical properties at subzero temperatures, can be used in temperatures up to 1000° F, and its melting point is 2370-2460° F. However, alloy 400 is low in strength in the annealed condition so, a variety of tempers may be used to increase the strength.

In what forms is Monel 400 Available at Mega Mex?

· Sheet

· Plate

· Bar

· Pipe & Tube (welded & seamless)

· Fittings (i.e. flanges, slip-ons, blinds, weld-necks, lapjoints, long welding necks, socket welds, elbows, tees, stub-ends, returns, caps, crosses, reducers, and pipe nipples)

· Wire

What are the characteristics of Monel 400?

· Resistant to seawater and steam at high temperatures

· Excellent resistance to rapidly flowing brackish water or seawater

· Excellent resistance to stress corrosion cracking in most freshwaters

· Particularly resistant to hydrochloric and hydrofluoric acids when they are de-aerated

· Offers some resistance to hydrochloric and sulfuric acids at modest temperatures and concentrations, but is seldom the material of choice for these acids

· Excellent resistance to neutral and alkaline salt

· Resistance to chloride induced stress corrosion cracking

· Good mechanical properties from sub-zero temperatures up to 1020° F

· High resistance to alkalis

Corrosion Resistant Monel 400

Alloy 400 is virtually immune to chloride ion stress corrosion cracking in typical environments. Generally, its corrosion resistance is very good in reducing environments, but poor in oxidizing conditions. It is not useful in oxidizing acids, such as nitric acid and nitrous. Nevertheless, it is resistant to most alkalis, salts, waters, food products, organic substances and atmospheric conditions at normal and elevated temperatures.

This nickel alloy is attacked in sulfur-bearing gases above approximately 700° F and molten sulfur attacks the alloy at temperatures over approximately 500° F.

Monel 400 offers about the same corrosion resistance as nickel but with higher maximum working pressures and temperatures and at a lower cost due to its superior ability to be machined.

In what applications is Monel 400 used?

· Marine engineering

· Chemical and hydrocarbon processing equipment

· Gasoline and freshwater tanks

· Crude petroleum stills

· De-aerating heaters

· Boiler feed water heaters and other heat exchangers

· Valves, pumps, shafts, fittings, and fasteners

· Industrial heat exchangers

· Chlorinated solvents

· Crude oil distillation towers

Fabrication with Monel 400

Alloy 400 can easily be welded by gas-tungsten arc, gas metal arc or shielded metal arc processes using appropriate filler metals. There is no need for post weld heat treatment, however, thorough cleaning after welding is critical for optimum corrosion resistance, otherwise there is the risk of contamination and embrittlement.

Finished fabrications can be produced to a wide range of mechanical properties when proper control of the amount of hot or cold working and the selection of appropriate thermal treatments is done.

Like most other nickel alloys, Monel 400 is typically tough to machine and will work harden. However, excellent results can e obtained if you make the correct choices for tooling and machining.

Mechanical Properties

Typical room temperature Tensile Properties of Annealed Material

*The ranges shown are composites for various product sizes and therefore are not suitable for specification purposes. Hardness values are suitable for specification purposes provided tensile properties are not also specified.
