ANSI B16.5 18000mm ASTM A789 2205 Duplex Seamless Pipe

Large Image : ANSI B16.5 18000mm ASTM A789 2205 Duplex Seamless Pipe

Product Details:

Place of Origin:	China
Brand Name:	TOBO
Certification:	SGS/BV/ABS/LR/TUV/DNV/BIS/API/PED
Model Number:	PIPE TOBO-S32760

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	USD Negotiated
Packaging Details:	Petroleum/Power/Chemical/Construction/Gas/Metallurgy/Shipbuilding etc
Delivery Time:	25 work days
Payment Terms:	L/C, T/T, Western Union
Supply Ability:	300 Ton/month

Contact Now

ANSI B16.5 18000mm ASTM A789 2205 Duplex Seamless Pipe

Description

Material:	Duplex Stainless Steel	Size:	Customized
Grade:	UNS S32205 / 2205	Chemical Composition:	Duplex Stainless Steel Ferritic /Austenitic Stainless Steel, 22%Cr
Surface Finish:	Pickled And Annealed, Bright Annealed, Polished
Highlight:	2205 Duplex Seamless Pipe , ASTM A789 Duplex Seamless Pipe , 2205 Duplex Seamless Pipe

High Strength Super Duplex Seamless Pipe 2205 / S32205 ASTM A789/A790
1. SCH5S-SCHXXS

2.Market:America,Africa,Middle East,Southeast of Asia

3.Product description:

Outer diameter

Φ6-630mm

wall thickness

1-50mm

Size

Customized

Manufacturing process

The steel melt shall be refined with AOD or equivalent

Chemical composition

Grade: S32760

Standard: UNS

W: 0.5-1.0

Others:

Cr + 3.3Mo + 16N≥40

C: ≤0.03

Si: ≤1.0

Mn: ≤1.0

P: ≤0.03

S: ≤0.01

Cr: 24-26

Ni: 6.0-8.0

Mo: 3.0-4.0

N: 0.2-0.3

Co: 0.5-1.0

Maximum length

18000mm/Customized

Mechanical properties Tensile strength:

σb≥750Mpa Elongation: δ≥25%

Typical working conditions

30% dilute sulfuric acid, below 60 ℃, annual corrosion rate <0.1mm

Manufacture Standard

ANSI : ANSI B16.5, ANSI B16.47, MSS SP44, ANSI B16.36, ANSI B16.48
DIN : DIN2527, DIN2566, DIN2573, DIN2576, DIN2641, DIN2642, DIN2655, DIN2656, DIN2627, DIN2628, DIN2629, DIN 2631, DIN2632, DIN2633, DIN2634, DIN2635, DIN2636, DIN2637, DIN2638, DIN2673
B.S : BS4504 , BS4504, BS1560, BS10

Package

Wooden cases, pallets, nylon bags or according to the customers' requirements

MOQ

1pcs

Delivery time

10-100 days depending on quantity

Payment terms

T/T or Western Union or LC

Shipment

FCA Tianjin/Shanghai, CFR, CIF, etc

Application

Petroleum/Power/Chemical/Construction/Gas/Metallurgy/Shipbuilding etc

Remarks

Other materials and drawings are available.
