|Grade:||C71500||Alloy Or Not:||Is Alloy|
|Price Term:||CIF CFR FOB Ex-Work, CIF, CFR, FOB, CNF||Material:||70/30 Copper Nickel Alloy C70600|
threaded copper pipe,
copper nickel tubing
Copper Nickel C715 - C71500
C715 Cupro-Nickel is a 70/30 copper nickel alloy that is almost entirely resistant to stress corrosion.
ASTM B151, ASTM B466, ASTM B111, ASTM B171, ASME SB466, ASME SB111, ASME SB151, ASME SB171, DIN 2.0872, BS 2871 CN102, EN CW352H, MIL-C-1726F, MIL-C-24679, MIL-T-16420K
C71500 COPPER NICKEL APPLICATIONS
Copper nickel alloy 715 finds its greatest application in areas of high temperatures and pressures combined with high velocity and destructive turbulence. The small iron content, up to 0.5%, gives the C715 alloy an extraordinary resistance to general corrosion and stress corrosion cracking, making it very suitable and ideal for the marine or industrial industries.
Common applications include:
C71500 Copper Nickel Specifications
|Bar||ASTM B151, B122, MILITARY MIL-C-15726|
|Pipe, Seamless||ASME SB466, ASTM B466|
|Pipe, Welded||ASME SB467, ASTM B608, B467|
|Plate||ASTM B122, MILITARY MIL-C-15726|
|Plate, Clad||ASTM B432|
|Plate, Condenser Tube||ASME SB171, ASTM B171, SAE J463, J461|
|Rod||ASTM B151, MILITARY MIL-C-15726|
|Rod, Welding||AWS A5.15|
|Sheet||ASTM B122, MILITARY MIL-C-15726, SAE J463, J461|
|Strip||ASTM B122, MILITARY MIL-C-15726|
|Tube, Condenser||ASME SB111, ASTM B552, B111, MILITARY MIL-T-15005, SAE J463, J461|
LIST OF STANDARD C71500 SIZES
Round Bar: ¼” Dia. thru 10”
Plate:3/16” thick thru 3”
Tube: Condenser tube
Pipe:¼” Standard (SCH 40) thru 10”
¼” Extra Heavy (SCH 80) thru 4”
½” Class 200 Mil-T-16420 K thru 10”
Fittings: Class 200, SCH 40, SCH 80, Butt-weld Fittings
Threaded and Socket-weld Fittings, 3000#/6000#
C96200 400# Socket-weld Fittings
Flanges: Slip-on, threaded, blind, Weld-neck Flanges
Ameritube has been providing C71500 Copper Nickel 70/30 according to the following standards:
AUTOMOTIVE: Power Steering Tube, Brake Lines
CONSUMER: Screw Lamp Bases
INDUSTRIAL: Condenser Plates, Condensers, Weld Torch Tips, Heat Exchanger Tubes, Valve Bodies,
Evaporator Tubes, Pressure Vessels, Distiller Tubes, Pump Impellers for Oil Refining, Ferrules, Evaporators
MARINE: Boat Hulls, Tube Sheet for Salt Water Service, Salt Water Pipe Fittings, Salt Water Piping Systems, Salt Water Piling Wrap, Hot Water Tanks, Salt Water Baffles, Propeller Sleeves, Ship Hulls, Water Hoses
Equivalencies Copper Nickel (70/30) tube/pipe
|DIN 86019 WL2.1972||CuNi10Fe 1.6Mn|
|Model Number:||90/10 Copper nickel alloy|
|Place of Origin:||China|
Q: Are you trading company or manufacturer ?
A: We are manufacturer ,You can see the Alibaba certification.
Q: How long is your delivery time?
A: Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge but need pay the cost of freight.
Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 50% T/T in advance ,balance before shippment.
Contact Person: Joy
