Product Details:
|
| Type: | Titanium Pipes | Application: | Industrial, Medical |
|---|---|---|---|
| Technique: | Seamless | Grade: | Gr.5,Gr.7,Gr.9 Etc |
| Shape: | Round | Stock: | Yes |
| High Light: | titanium exhaust tubing,bending titanium tubing |
||
Product Description
Size: OD2-508*WT0.3~40.0*L200-15000mm
Product Description:Top quality Titanium alloy seamless round tubes random length produce and supply
Manufacture Standard:ASTM B338, ASTM B337, ASTM B861,ASTM B862, GOST 22897, JIS H4631 or as per clients' requirements
titanium pipe Grades:GR1,GR2,GR3,GR5,GR7,GR9,GR11,GR12,GR16,GR17
Applications
Chemical industry
Blades,discs,rings,airframes,fasteners,components.
Vessels,cases,hubs,forgings.Biomedical implants
| Grade | Elongation(%) | Tensile Strength (Min) | Yield Strength (Min) | ||
| ksi | Mpa | ksi | Mpa | ||
| Gr1 | 24 | 35 | 240 | 20 | 138 |
| Gr2 | 20 | 50 | 345 | 40 | 275 |
| Gr3 | 18 | 65 | 450 | 55 | 380 |
| Gr4 | 15 | 80 | 550 | 70 | 483 |
| Gr5 | 10 | 130 | 895 | 120 | 828 |
| Gr7 | 20 | 50 | 345 | 40 | 275 |
| Gr9 | 15 | 90 | 620 | 70 | 438 |
| Gr12 | 18 | 70 | 438 | 50 | 345 |
Titanium Alloy GR.5 Chemiacl Composition(%)
| Alloy Designation | Element | O | V | Fe | Al | Ti |
| Titanium Alloy GR.7 | Max.% | 0.2 | 4 | 0.25 | 6 | 90 |
| Mechanical Propeties | Titanium Alloy GR.5 |
| Density | 4.43g/cm3 |
| Melting Point | 1604~1660ºC |
| Tensile Strength Min (Mpa) | 950Mpa |
| Yield Strength Min (Mpa):0.2% offset | 880Mpa |
| Elongation A 5%(Min.) | 65/40 |
| HB Max | 334 |
Applications of Titanium Pipe / Titanium Tube:
Process methods: cold rolling
Surface delivery conditon:solution annealed and pickled or polished
Length:Max15 meters
Packing: in seaworthy wooden cases or in wooden box
MOQ:100KGS each size
Delivery date: Min. 10 days
Certificates: ISO9001:2000 quality system and Mill test Certificate supplied
Product preview
Company introduction
Shanghai TOBO GROUP has been engaged in flanges, piep fittings more than 7 years. Our experiecnced and professional team of bending, and full tools and equipments make us provide customers almost all kind of metal U-bent tubes with high quality. With our unique manufacturing capabilities, Shang Hai TOBO GROUP also supply customer with value-added service.
Certificates
Packing
Standard export packing, seaworthy packing, bundles, plastic bag, woven bag, wooden cases, plywood case, iron case, or as per customer require
