90/10 Cupro Nickel is widely used in sea water. It has very good corrosion resistance to clean moderately polluted marine or estuary water, even containing dissolved incondensable gases.
-
This alloy is virtually immune from stress-corrosion cracking and hot spot denickelification.
-
In clean sea water, a velocity of up 2.2-2.5 m/s (7.5-8.5 ft/s) is accepted while 4 m/s (13 ft/s) is the upper limit for clean fresh or slightly saline solutions.
C70600 Copper Nickel Specifications
| End Product |
Specification |
| Bar |
ASTM B151, B122, MILITARY MIL-C-15726 |
| Pipe, Seamless |
ASME SB466, ASTM B466 |
| Pipe, Welded |
ASME SB467, ASTM B608, B467 |
| Plate |
ASTM B122, MILITARY MIL-C-15726 |
| Plate, Clad |
ASTM B432 |
| Plate, Condenser Tube |
ASME SB171, ASTM B171, SAE J463, J461 |
| Rod |
ASTM B151, MILITARY MIL-C-15726 |
| Rod, Welding |
AWS A5.15 |
| Sheet |
ASTM B122, MILITARY MIL-C-15726, SAE J463, J461 |
| Strip |
ASTM B122, MILITARY MIL-C-15726 |
| Tube, Condenser |
ASME SB111, ASTM B552, B111, MILITARY MIL-T-15005, SAE J463, J461 |
LIST OF STANDARD C706 SIZES
Round Bar: ¼” Dia. thru 10”
Sheet:065”, .125”
Plate:3/16” thick thru 3”
Tube: Condenser tube
Pipe:¼” Standard (SCH 40) thru 10”
¼” Extra Heavy (SCH 80) thru 4”
½” Class 200 Mil-T-16420 K thru 10”
Fittings: Class 200, SCH 40, SCH 80, Butt-weld Fittings
Threaded and Socket-weld Fittings, 3000#/6000#
C96200 400# Socket-weld Fittings
Flanges: Slip-on, threaded, blind, Weld-neck Flanges
Ameritube has been providing C70600 Copper Nickel 90/10 according to the following standards:
- ASME SB-111
- ASME SB-466
- ASTM B-111
- ASTM B-466
- MIL-T-15005f
- MIL-T-16420k Class 200, 700, 1650, 3300, and 6000
Typical Uses for C706 Copper Nickel "90/10":
AUTOMOTIVE: Power Steering Tube, Brake Lines
CONSUMER: Screw Lamp Bases
INDUSTRIAL: Condenser Plates, Condensers, Weld Torch Tips, Heat Exchanger Tubes, Valve Bodies,
Evaporator Tubes, Pressure Vessels, Distiller Tubes, Pump Impellers for Oil Refining, Ferrules, Evaporators
MARINE: Boat Hulls, Tube Sheet for Salt Water Service, Salt Water Pipe Fittings, Salt Water Piping Systems, Salt Water Piling Wrap, Hot Water Tanks, Salt Water Baffles, Propeller Sleeves, Ship Hulls, Water Hoses
Equivalencies Copper Nickel (90/10) tube/pipe
|
KS D5301
JIS H3300
|
C7060T |
| ASTM B111 |
C70600 |
| ASTM B466 |
C70600 |
| BS2871 {PART2} |
CN102 |
| AS1752 |
C70600 |
| DIN17664 |
CuNi10Fe 1Mn |
| DIN 86019 WL2.1972 |
CuNi10Fe 1.6Mn |
| EEMUA 144 |
7060X |
| MIL-T-16420K |
706 |
| EN12449 |
CW352H |
PLUMBING: Flanges
| Brand Name: |
TOBO |
| Model Number: |
90/10 Copper nickel alloy |
| Certification: |
SGS/BV/ABS/LR/TUV/DNV/BIS/API/PED |
| Place of Origin: |
China |
