Product Details:
|
| Material: | Duplex Stainless Steel | Standard: | ASME,ASTM |
|---|---|---|---|
| Grade: | S31803 | Thickness: | 40 |
| Size: | 10" | Type: | Welded |
| High Light: | stainless steel threaded pipe,seamless stainless steel tubing |
||
|
Standard |
Duplex Stainless Steel (S32205) |
|
UNS |
S31803 |
|
WERKSTOFF NR. |
1.4462 |
|
Grade |
C |
Mn | Si | P | S | Cr | Mo | Ni | N |
|
S31803 |
0.03 max |
2.0 max |
1.0 max |
0.03 max |
0.02 max |
min: 21.0 max: 23.0 |
min: 2.5 max: 3.5 |
min: 4.5 max: 6.5 |
min: 0.08 max: 0.20 |
|
Grade |
Tensile Strength ksi(min) |
Yield Strength 0.2% ksi (min) |
Hardness (HB) MAX |
Elongation % |
|
S31803 |
90 | 65 | 217 | 25 |
| Tye |
Pipe, Reducer,Flange,Tee,Forged Fittings,Plate,Coil |
| Standard | DIN,EN,ASTM,BS,JIS,GB,ASME(ASME16.9/16.20) |
| Application | Petroleum/Power/Chemical/Construction/Gas/Metallurgy/Shipbuilding etc |
FAQ
We are manufacturer ,You can see the Alibaba certification.
Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.
Yes, we could offer the sample for free charge but need pay the cost of freight.
Payment<=1000USD, 100% in advance. Payment>=1000USD, 50% T/T in advance ,balance before
If the quantity of order is not very big,we could send them to you by express delivery,such as TNT,DHL,UPS OR EMS etc.
If order is big ,we will advise you use Air Shipping or Sea Shipping through your nominated forwarder agent.Our long-term cooperated agent also available.
